• All-analog audio path with 2 VCOs with continuously variable waveshape, noise generator, resonant multimode VCF and VCA
• 2 independent analog VCOs with Saw, Triangle and Pulse waveforms with continuously variable shape including PWM of the square wave and a separate white noise generator
• A 2-pole multimode OTA-based sweepable analog resonant multimode filter with LPF, HPF, BPF
• LFO with Sine, Triangle, Square, Up Saw, Down Saw, Random and Sample-and-Hold to modulate Pitch, Filter and Amp
• AD (Filter) + AR (Amp) envelopes (full ADSR control available via MIDI CC or software editor)
• 40 onboard controls and LED display
• 100 onboard presets
• 10 mode, 4-octave arpeggiator
• Real-time and step edit 16-step sequencer with 20 automatable parameters
• Onboard multi-touch 27-note chromatic and scale keyboard with 13 scales
• Sync Delay audio effect and 5 performance effects
• Self-tuning with auto-tune calibration
• USB MIDI and 2.5 mm jack MIDI IN/OUT (cables included)
• Audio In to daisy chain other audio devices with no need for a mixer
• Mac/PC/iOS Editor
• Complete MIDI implementation with all parameters and clock can be controlled via MIDI CC
• Battery (4xAA) or USB powered
• Ultra-portable and lightweight
• Designed and made in Italy



Synthesis

• Type: Analog
• Polyphony: 1 voice
• Synthesis structure: 2 VCO, Noise generator, 1 VCF, 1 VCA, 2 EG, 1 LFO
• VCO variable shape waveforms: Triangle, Sawtooth, Pulse with variable pulse width
• VCF: 2-pole resonant multimode filter with Cutoff, Resonance, Env Amount, Drive
• LFO: 7 shapes (Sine, Triangle, Square, Saw Up, Saw Down, Random, Sample & Hold), Rate
• Modulation Destinations: Amp, Pitch, Filter, PWM, Waveshape (PWM and Waveshape via MIDI CC)
• EG: 2 for Filter and Amplitude (full ADSR is available via MIDI)

Preset

• 100 Presets (20 factory non-writable, 80 user)

Keyboard and controls

• 7 Knobs (4 matrix, 3 fixed)
• 13 Selectable scales (Chromatic, Major, Minor, Major Pentatonic, Minor Pentatonic, Major Blues, Minor Blues, Harmonic Minor, Mixolydian, Dorian, Klezmer, Hungarian Gypsy, Spanish Gypsy, Japanese, South-East Asian)

Sequencer

• 16-step sequencer
• Real-time and step recording with parameter recording
• Real-time parameter recording per-step
• 3 directions: Forward, Backward, Forward and Backward
• Selectable length between 1 and 16 steps

Arpeggiator

• 10 Mode Arpeggiator
• 4 octave range
• Hold control

Effects

• Delay
• Dive, Scoop, Vibrato, Wah, Tremolo

Connections

• Audio Out: Mini-jack 3.5mm stereo (mono summed)
• Audio In: Mini-jack 3.5mm stereo (mono summed)
• 2 x MIDI 2.5mm mini-jack to DIN cables (IN/OUT)
• 1 Micro USB*

Power

• 4x AA Batteries
• Micro USB connector



*USB power has inherent ground noise, so when connecting the UNO Synth directly to your computer via USB, you may hear more noise and interference than when the synth is connected to a USB wall charger or running via batteries. With the direct computer connection, you can reduce the USB ground noise and other interference by either using a USB isolator or a custom TRS cable into a balanced input on your preamp or audio interface where the ground is not connected at the balanced input side.

Package includes

• UNO Synth
• 1x Micro USB to USB cable
• 2x MIDI jack 2.5mm to DIN cables
• 4x AA batteries



Dimensions

• Size: 25.6cm/10.1" x 15cm/8.9" x 4.9cm/1.93"
• Weight: content 400g/14.1oz (batteries excluded)

UNO Synth Editor Compatibility



iOS Devices

• Compatible with 64-bit iPhone, iPad, and iPod touch. iOS 10 or later is required.



Computers

• 64-bit application. Requires a 64 bit CPU and Operating System.
• Mac: macOS 10.11 or later.
• Windows: Windows 8 or later.



• UNO Synth Quick Start Guide
• UNO Synth User Manual
• UNO Synth Editor User Manual
